AT528L Handheld Battery meter

AT528L is minature handheld battery tester adopting high performance 32 bits ARM micor-processor control. With built-in high capacity lithium battery , it can realize super long standby time.

Given 3.5 inch true color LCD display, you can read tested data conveniently. By testing battery voltage and resistance, AT528 can judge quickly the degradation of battery.it can measure 0.1mΩ~200.0Ω resistance, 0-50V DC voltage, with 3200 digits display of resistance, 3000digits display of voltage.It follows vector measuring principle to test resistance, differential principle to measure voltage, enabling it to accuratly measure open circuit.

With special sorting function and sorting beep setting, it can carry out simple sorting.

This instrument can restore 500 groups of data.
AT528L has both portability of handheld meter and superior performance of bentop device. In addition, with USB insterface realizing remote control and data collecting and analysis, it is suitable for inspection of assembly line of variouss kinds of battery and degradation review of UPS battery.

FEATURES
Fresh and dazzling two-color casting shell
Battery and external power supply mode
Four terminal test
Built-in Mini-USB interface
Compatible with SCPI instruction set
Backlight adjustment
Power consumption≤5W
Super long continuous working time ≥ 8h
