CA6416 Clamp-On Ground Resistance Tester

Sold By

NCIEM

(0 customer reviews)

Top Selling Products

Testo 270 Cooking Oil Tester

SAR2,000.00
Hioki DT4222: Digital Multimeter

SAR390.00
HTA102 Sound level Meter with Calibrator

SAR4,000.00
Megger MIT1525 - 15kV Insulation Resistance Tester

SAR30,000.00
RD C.A.T4+ and GENNY4 Underground Radiodetection Cable & Pipe Locator

SAR15,000.00
Flir E8-XT InfraRed Camera with MSX & WiFi

SAR15,000.00

Description Downloads Reviews

KEY FEATURES

● Alarms on Ω, A and V
● 300 storage locations
● Buzzer and automatic power-off
● Large measurement range: 1,500Ω / 500µH / 40A
● Automatic Pre-Hold mode when the clamp is opened
● Real-time clock for time/date-stamping of measurements
● Automatic calibration of jaw opening distance at start-up

PRODUCT OVERVIEW

The Chauvin Arnoux CA6416 earth clamps delivered in a carrying case are ideal for quick earth-loop resistance measurements. 600V CAT IV, they display the earth voltage with a dangerous voltage alarm and provide additional safety during measurement. They are particularly easy to use thanks to ergonomic innovations such as a force compensation system to keep the clamp open without any effort and an OLED display, offering visibility over an angle of 180° whatever the lighting conditions. The automatic PRE-HOLD function when the clamp is opened and the automatic jaw calibration function at power-up help to optimize processing of the measurements provided by the clamps. They also allow users to display the impedance transposed to a frequency close to the network frequency, thus reducing measurement errors when low values are involved. On the same screen, they offer simultaneous display of the impedance and leakage current (Ω+A), the earth voltage and the breakdown of the resistive and inductive parts of the ground impedance.

Download

There have been no reviews for this product yet.
