KPS‐MA500 Insulation tester

Sold By

NCIEM

(0 customer reviews)

Top Selling Products

Testo 270 Cooking Oil Tester

SAR2,000.00
Hioki DT4222: Digital Multimeter

SAR390.00
HTA102 Sound level Meter with Calibrator

SAR4,000.00
Megger MIT1525 - 15kV Insulation Resistance Tester

SAR30,000.00
RD C.A.T4+ and GENNY4 Underground Radiodetection Cable & Pipe Locator

SAR15,000.00
Flir E8-XT InfraRed Camera with MSX & WiFi

SAR15,000.00

Description Downloads Reviews

Features
*Broad Range of Testing Voltage :
-Testing voltages with broad range can be generated (from 250 V to 5 KV).
-Testing voltage can be preset as 250 V, 500 V, 1 KV, 2.5 KV, or 5 KV, or as a voltage increasing or decreasing in steps of 25 V or 100 V.
*Insulation Diagnosis :
-PI and DAR can be automatically calculated and displayed;
-Step-voltage measurements and temperature compensation is carried out.
*Large Storage Memory :
-Up to 100 manually tested data and 10 groups of log-test data can be saved.
-Test data can be read on LCD, or uploaded to PC
*Clear Display :
-Large-screen display. Test result is displayed with indication through a graduation bar.
-LCD screen is backlit, which is suitable for viewing when it is dark.
*PC Communication :
-The meter is equipped with a USB interface, through which the saved test data can be uploaded to a PC for further table/figure making and report generating with convenience.
*Robust and Durable :
-With a compact structure, the tester is robust, durable and portable.
*Powered by Batteries :
-With a selection switch, the tester can be powered by an alkaline battery.
-This tester can be continuously operated for a longer period of time than similar meters if a LR14 alkaline battery is used.
